Information
pH Oxy Cond
Sensor Monitor
Shows the raw values available fom the connected sensor:
pH, analog
pH, digital, glass
pH, digital, ISFET
pH, ORP
Cond, analog
Cond, digital
Oxy, digital
MemoLog (Memosens only)
Displays the individual calibration records. You have the possibility to delete
individual entries or all entries. The following parameters are displayed:
• Sensor type
• Manufacturer
• Calibration date
• Serial no.
• Zero point
• Slope
• Load conditions
• Measuring point (TAG)
Background: The device provides a calibration data logger, which must be
activated in the confi guration menu. With "MemoLog" activated, up to 100
calibration records can be directly saved to the device. Then, the complete
Memosens index structure will be recorded after every calibration. The Me-
moSuite software allows convenient management of the calibration data.
52
mV, temperature, temperature detector, temp. resis-
tance
mV, temperature, glass impedance
mV, leakage current, temperature
mV, temperature
Resistance, conductance, temperature, temperature
detector, temperature resistance
Resistance, conductance, temperature
Sensor current, leakage current, polarization voltage,
partial pressure, air pressure, temperature
