In the example in grey this gives:
• Byte 2=0x02: register 302, channel A configured for a 4-20mA sensor
• Bytes 3 to 5=0x0C3500=800,000 in decimal i.e. A value measured on channel A of: 800,000,x10=8,000,000nA i.e. 8mA
• Byte 6=0x01: register 304, channel B configured for a 0-10V sensor
• Bytes 7 to 9=0x4C4B40=5,000,000 in decimal i.e. a value measured on channel B of: 5,000,000 µV i.e. 5V

4.1.5 Data Frame

This frame (0x42) contains the values measured on the different sensors
0 1
Code Status
0x42 Cf Status S302
0x42 0x42 0x02
Description de la trame :
• Byte 2: Type of the sensor on channel A. Configured by the user (register 302).
• Bytes 3 to 5: Value measured on channel A.
• If the type of sensor is 0-10V: The value is expressed in µV
• If the type of sensor is 4-20mA: The value is expressed in nA
• Byte 6: Type of the sensor on channel B. Configured by the user (register 304).
• Bytes 7 to 9: Value measured on channel B.
• If the type of sensor is 0-10V: The value is expressed in µV
• If the type of sensor is 4-20mA: The value is expressed in nA
In the example in grey this gives:
• Byte 2=0x02: register 302, channel A configured for a 4-20mA sensor
• Bytes 3 to 5=0x0C3500=800,000 in decimal i.e. A value measured on channel A of: 800,000,x10=8,000,000nA i.e. 8mA
• Byte 6=0x01: register 304, channel B configured for a 0-10V sensor
• Bytes 7 to 9=0x4C4B40=5,000,000 in decimal i.e. a value measured on channel B of: 5,000,000 µV i.e. 5V

4.1.6 Summary of the conditions of the transmission of the uplink frames

The table below summarizes the conditions of the transmission of the different uplink frames:
Coding Description
0x10 Frames of information on the product
0x11 configuration
0x12
0x13
0x14
0x20 Frames of information on the network
configuration
0x30 Keep Alive frame
0x42 Data Frame
2 3 4
Value read on the channel A sensor
0x0C3500
• Start-up of the product
• Exit from the configuration mode (AT Command)
• Periodically if the sensors are disabled (Keep Alive period)
• Start-up of the product
• Exit from the configuration mode (AT Command)
• Start-up of the product
• Periodically in the «event" mode
• Start-up of the product
• Event on digital input (event mode)
• Passing a threshold (event mode)
• End of period (periodic mode)
5 6 7
PAYLOAD
S304 Value read on the channel B sensor
0x01
Transmission scenarii
8 9 10
X
0x4C4B40
