S+S Regeltechnik AERASGARD ACO2 Notice D'instruction page 21

G
®
HYGRASGARD
TELEGRAMS
Function 04 Read Input Register
Register
3x0001 CO2
3x0002 CO2
3x0003 VOC
3x0004 VOC
3x0005 Temperature
3x0006 Temperature
3x0007 Relative humidity
3x0008 Relative humidity
3x0009 Atmospheric pressure
3x0010 Atmospheric pressure
3x0011 VOC ppb
3x0012 VOC ppb
Function 06 Write Single Register & Function 16 Write Multiple Register
Register
4x0001 Physical parameter displayed
Standard display (cyclic):
VOC in %,
CO2 in ppm,
temperature in °C,
relative humidity in % r.H.
alternative display (static):
CO2 in ppm
VOC in %
Temperature in °C
Relative humidity in % r.H.
Atmospheric pressure in hPa
Freely configurable display
4x0002 7-Segment Value
4x0003 7-Segment Value
4x0004 –
4x0005 Segment Pattern
4x0006 Dot Matrix Character A
4x0007 Dot Matrix Character B
4x0008 Dot Matrix Character C
4x0009 Dot Matrix Character D
4x0010 Dot Matrix Character E
4x0011 Dot Matrix Character F
4x0012 Dot Matrix Character G
4x0013 Dot Matrix Character H
4x0014 Dot Matrix Character I
4x0015 Dot Matrix Character J
4x0016 Dot Matrix Character K
4x0017 Dot Matrix Character L
4x0018 Dot Matrix Character M
4x0019 Dot Matrix Character N
AFTM- ⁄ KFTM - LQ - CO2 - Modbus | Telegrams
Parameter
Sampling 4 s
Filtering 32 s
Sampling 4 s
Filtering 32 s
Sampling 4 s
Filtering 32 s
Sampling 4 s
Filtering 32 s
Sampling 4 s
Filtering 32 s
Sampling 4 s
Filtering 32 s
Parameter (display)
Data Type
Signed 16 bit
Signed 16 bit
Signed 16 bit
Signed 16 bit
Signed 16 bit
Signed 16 bit
Signed 16 bit
Signed 16 bit
Signed 16 bit
Signed 16 bit
Unsigned 16 Bit
Unsigned 16 Bit
Data Type
Index on display Unsigned 8 bit
–
1
2
3
4
5
–
Signed 16 bit
Signed 8 bit
Unsigned 16 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
Unsigned 8 bit
21
Value Range
350...5000 350...5000 ppm
350...5000 350...5000 ppm
0...1000 0.0...100.0 % VOC
0...1000 0.0...100.0 % VOC
–350...800 –35.0...+80.0 °C
–350...800 –35.0...+80.0 °C
0...1000 0.0...100.0 % r.H.
0...1000 0.0...100.0 % r.H.
700...1100 700...1110 hPa
700...1100 700...1110 hPa
0...60 000 ppb 0...60 000 ppb
0...60 000 ppb 0...60 000 ppb
Value Range
0...10 0...10
Default
0
setting
1
2
3
4
5
10
-999...9999 -999...9999
-9...99 -9...99
See Binary Pattern
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
