6.2.2 Guidance concept

Rotation-locked guide of a guide carriage on two guide tubes arranged in parallel.
Guide tube: precision tube as per DIN EN 10305, Stainless-steel profile material 17458,
Surface roughness R = 0.4 µm
a
Screw bearing: sealed deep-groove ball bearing, optional slide bearing
After receiving this linear unit, check the device for possible damage and missing components.
If you find any faults, inform RK Rose+Krieger GmbH of these immediately. The linear unit is
delivered ready for operation, but without a control system and without accessories.

6.3 Dimensions

Linear units are produced individually to length in accordance with your specification.
The width and height of this linear unit is determined from the choice of size and configuration
and can be taken from the Linear Components catalogue.

6.4 Load data

In dynamic operation, the following must be considered for the design:

6.4.1 Load data* EP-II

Fx
Total length
500
(mm)
Version
EP-II 30 800 N
EP-II 40 1000 N
* referred to guide carriages (deflection of the guidance unit f=0.5 mm, static, covering the end
elements)
Fx max = m*a [m/s2]
Admissible forces
Fy
500 1000 1500
1000 N 800 N 500 N
3500 N 2600 N 1300 N
6. Product information
Fz
500 1000 1500
550 N 300 N 100 N
2000 N 580 N 120 N
Admissible torques
Mx My Mz
60 Nm 60 Nm 75 Nm
120 Nm 130 Nm 150 Nm
