PROline Promag 53 PROFIBUS-DP/-PA
Endress+Hauser
Electrical connections
Power supply connection
Esc
- +
➀
Esc
-
+
B
➀
Fig. 1: = power supply cable


A = view A
B = view B
The table below contains the values that are identical for all versions, irrespective of the
type code.
Transmitter Promag 53
Terminals 1
L (+)
Designation Power supply
Functional AC: U = 85...260 V
values or
AC: U = 20...55 V
or
DC: U = 16...62 V
Power consumption:
15 VA / 15 W
A
E
B
E
2 3
N (–)
Ground


A
27
26
25
24
23
22
21
20
N (L-) 2
L1 (L+) 1
1 2 20 21 22 23 24 25 26 27
➀
0
<
➀
7
