Programming Overview
3-9
Menu-
No.
Entry
Selection
point
5
Key switch function (J7)
0*
Open/Close pulse input
1
Block control panel
2
Block external control elements
3
Block control panel and external control elements
50
4
Activating the control elements for 10 secs.
5
Switch to dead man's Close
6
Switch to half opening of the door
7
Pulse input for Open-Stop-Close
Pulse input for Half Open-Stop-Close
8
9
AR - automatic closing
10
Pulse input for (smoke-heat exhaust) (menu 55)
Function of external impulse generators
0*
off
1
Dead man OPEN / Dead man CLOSE
2
Impulse OPEN / Dead man CLOSE
51
3
Impulse OPEN / Impulse CLOSE
4
Impuls 1/2 Öffnung / Impuls Zu
5
AR - automatic closing
AR - automatic closing, half opening
6
Open-close operation
7
52
001-256
Entering the control address
Module
off
0*
53
1 - 4
DC-module
Wireless closing edge, RadioSafe JCM
5
6
W-LAN module
55
Door setting for smoke-heat exhaust position
- -
Exit menu
6
Programming the START button on the transmitter
60
Programming button for 1/2-opening on the transmitter
61
62
Programming the light button on the transmitter
Deleting radio codes (press for 5 sec.)
63
Start button operating mode
0*
off
1
Impulse open-stop-close
64
AR - automatic closing
2
Open-close operation
3
- -
Exit menu
Menu
30-
37
(J1)
Item
1x
Menu-
No.
Entry
Selection
point
7
70
0 - 99
Open speed (1% - 100% motor speed)
71
0 - 99
Close speed (1% - 100% motor speed)
72
0 - 99
Soft run(1% - 100% motor speed)
0 - 39
Acceleration time open
73
0 - 39
Braking time open
74
0 - 39
Acceleration time close
75
0 - 39
Braking time close
76
Soft run distance (number of motor revolutions)
Close only before end position (0 - 9 motor revolutions)
0 - 9
77
Open and close before end position (0 - 9 motor revolutions)
10 - 19
Only before open end position (0 - 9 motor revolutions)
20 - 29
Motor brake
Type A,
dropout delay
78
0 - 9
10 - 19
Type B,
dropout delay
Drive select, see separate sheet
79
0*
No drive motor selected
- -
Exit menu
9
Selecting the door's service intervals
0*
no service interval
1
10000 cycles
2
20000 cycles
3
30000 cycles
4
40000 cycles
90
5
50000 cycles
6
60000 cycles
7
80000
cycles
8
100000
cycles
9
120000 cycles
10
150000 cycles
11
200000 cycles
12
250000 cycles
91
Issue of cycles counter
96
Issue of operating hours counter hours
97
Issue of error memory hours error code
98
Issue of software version serial-no. date
99
Resetting of factory setting (press for 5 sec.)
- -
Exit menu
Enter
(0.1 secs. - 4.0 secs.)
(0.1 secs. - 4.0 secs.)
(0.1 secs. - 4.0 secs.)
(0.1 secs. - 4.0 secs.)
(0 - 350ms)
(0 - 350ms)
-
-
cycles
-
-
-
-
-
* Factory defaults
