iTEMP® HART® Communication
Installation check
Function check

Commissioning

Endress+Hauser
3 Commissioning
3.1

Installation and function check

Monitor all connections making sure they are tight. In order to guarantee fault-free
operation, the terminal screws must be screwed tightly onto the connection cables.
Measuring the analogue 4-20 mA output signal or following failure signals:
Measurement range
undercut
Measurement range
excess
Sensor break; sensor
1
short circuit
1. not for thermocouples
3.2 Commissioning
Once the power supply has been connected the transmitter is operational.
Hint!
If there are any communication faults in the Microsoft
®
Windows 2000 operating system please follows these instructions:
Switch of the 'FIFO active' setting.
In order to do this proceed as follows:
• Windows NT
®
Version 4.0:
Using the menu 'START' 'SETTINGS' 'SYSTEM CONTROL' 'CONNECTIONS' select the
menu point 'COM-Port'. Switch off the 'FIFO active' command off using the menu path
'SETTINGS' 'EXPANDED'.
• Windows
®
2000:
Select 'Advanced settings for COM1' from the 'START' → 'SETTINGS' → 'SYSTEM
CONTROL' → 'SYSTEM' → 'HARDWARE' → 'DEVICE MANAGER' → 'CONNECTIONS
(COM and LPT)' → 'COMMUNICATION CONNECTION (COM1) → 'CONNECTION
SETTINGS' → 'ADVANCED' menu. Deactivate "Use FIFO buffer".

3.2.1 Quick Setup

Using the Quick Setup the operator is led through all the most important unit functions
that must be set up for standard measurement operation of the unit. Using the HART
hand module a quick set-up of the black highlighted fields of the HART
(see fig. 3-2) is possible.
Using the Commuwin II operating matrix (see fig. 3-3) a quick set-up is possible with
the following fields:
• Type of sensor (V2H0)
• Unit meas. value (V2H2)
• Value for 4 mA (V2H4)
• Value for 20 mA (V2H5)
• Connection (V2H6).
linear fall to 3.8 mA
linear rise to 20.5 mA
≤ 3.6 mA or ≥ 21.0 mA
3 Commissioning
® ®
Windows NT Version 4.0 and
®
function matrix
®
25
