Preparation
Carton Inventory
Save the carton and packing material until the installation and adjustment is complete.
Instructions for the accessories will be attached to the accessory and are not included in this
manual. The images throughout this manual arefor reference only and your product may look
different.
1. Header bracket
2. Pulley
3. Door bracket
4. Curved door arm
5. Straight door arm
(Packaged inside front rail section)
6. Trolley
7. Emergency release rope and handle
8. Rail (1 front and 4 center sections)
9. Hanging brackets (2)
(Packaged inside the front rail section)
10. Garage door opener (motor unit)
11. Chain spreader with screws - Model C2405
12. "U" bracket
13. Chain and cable or chain (D2405C and D21202C only)
14. The Protector System®
Safety reversing sensors with 2 conductor white and white/black wire attached: sending
sensor (1), receiving sensor (1), and safety sensor brackets (2)
15. Remote control
16. Push Button Door Control - Models C2202C, D2101C, C2102C
Multi-Function Control Panel - Model C2405C, D2405C
17. White and red/white wire
18. Installation manual and all warning labels
19. Sprocket cover - Model C2405C, D2405C
See Hard ware page 6.
Goto chamberlain.com for replacement or additional accessories:
3-button remote control model 953EV-P2
Wireless keypad model 940EV-P2
