Installation
5.6
Disassembly
1.
Loosen cable screw (20).
2.
Loosen air regulator (21/1) by turning it anti-clockwise.
3.
Unlock and remove pneumatic button (38/1; 38/2) by turning
it anti-clockwise.
4.
Unlock cover (113). See "Fig. 20" on page 34.
5.
Loosen screws (112) and remove lighting cover (110).
6.
Loosen screws (49) and remove stainless steel cover (93).
7.
Loosen screws (95) and remove suction housing (107).
8.
Loosen screws (52) and remove support ring (28) and
support ring seal (27).
42 EN
08|2018
