ideo door entry system with distributor, 2 repeaters and d.c lock release.
See example 'C' and important notes in 'operation modes' (pág. 43).
The installation diagram shows the connection of a video door entry system with one door panel to
access the building
REMEMBER: Installations with distributors, t
installed for each repeater must never exceed 32 units.
FA-V2PLUS
SEC
PRI
- - +
230 110 0
Main
with distributors, 2 repeaters in daisy chain
+
INSTALLATION DIAGRAMS
and d.c lock release.
he total number of elements (monitors/telephones)
V2Plus door panel
M
BUS CV2
M =Master.
SW1
(1)
CV1 +12
