52
D
aisy chain installation for
See example 'A' and important notes in 'operation modes' (page 43).
REMEMBER: The total number of daisy chain elements (monitors/telephones) installed for each
repeater must never exceed 16 units.
FA-V2PLUS
PRI SEC
- - +
230 110 0
Main
FA-V2PLUS
PRI SEC
230 110 0 - - +
Main
(1)
IMPORTANT: To configure and to program each equipment see the appropiate instruction book.
Video door entry system without distributor, 1 repeater & d.c lock release.
Tekna V2Plus
*
HZ
BUS IN BUS OUT
Tekna V2Plus
HZ
BUS IN BUS OUT
RD-V2Plus
+
BUS IN BUS OUT
+

INSTALLATION DIAGRAMS

Sw2
(1)
PA PB
Sw2
(1)
PA PB
V2Plus door panel
BUS
Configuring the end of
*
line in the last monitor.
M =Master.
M
SW1
(1)
CV2 CV1 +12
