Fig. J
Fig. K
Fig. L
Convert to Edging Mode (Fig. M)
The trimmer can be used in trimming mode or edging
mode to trim overhanging grass along lawn edges and
flower beds.

WARNING:
power source before making any adjustments.

WARNING:
edger, stones, pieces of metal and other objects can be
thrown out at high speed by the line. The trimmer and
guard are designed to reduce the danger. However,
MAKE SURE that other persons and pets are at least
100' (30 m) away.
1. To operate as a maintenance edger, release the height
adjust locking clamp
Disconnect the plug from the
When being used as an
7 .
2. Hold the trimmer with one hand on the auxiliary handle
and one hand on the tube near the trimmer head. Then
rotate the tube and head counterclockwise.
3. Close the height adjust locking clamp.
nOTE: The tube and head will only rotate in one direction.
nOTE: The Auto Feed System may not operate correctly if
wire edge guide 11 is not used.
4. To return to the trimming position, release the height
adjustment locking clamp. Rotate the tube and head
clockwise. Close the height adjustment locking clamp.
Fig. M
7
Edging (Fig. A, N)
Optimum cutting results are achieved on edges deeper than
2" (50 mm). Do not use this trimmer to create trenches.
1. To make a closer cut, slightly tilt the trimmer.
2. Return to the trimming postion by loosening the lock
collar and rotating the lower housing back 180°. The tool
will lock in the trimmer position.
Fig. N
