Note
For sensitive textiles, we recommend using the
KÄRCHER non-stick electric iron plate BE 6006.
Note
The iron plate must be hot to prevent steam from con-
densing on the sole plate and dripping onto the ironing
laundry.
The iron can be held vertically for steaming curtains,
dresses, etc.
1. Set the temperature controller of the iron within the
selected range (
As soon as the orange heating indicator light of the
iron goes out, ironing can be started.
2. Press the "steam" switch (top) or the "steam" switch
(bottom).
 Steaming at intervals: Press the "steam" switch.
Steam flows out as long as the switch is pressed.
 Continuous steaming: Pull the lock for the
"steam" switch backwards until it engages. Steam
flows out continuously. To release, push the lock
forward.
3. Before ironing and after pauses in the ironing pro-
cess, direct the blast of steam onto a cloth until the
steam flows evenly.
Dry ironing
ATTENTION
Damage to the device
Water shortage in the steam boiler leads to damage to
the device
Make sure that there is water in the steam boiler.
ATTENTION
Damage to garments
Failure to observe the ironing information in the garment
may result in damage.
Observe the ironing information in the garment.
1. Set the temperature controller of the iron in accord-
ance with the garment.
Synthetics
Wool, silk
Cotton, linen
2. Wait until the iron's heating indicator light goes out.
The iron is ready for ironing.

Care and service

Descaling the steam boiler
Note
Since the lime clogs the appliance, we recommend des-
caling the appliance based on the number of times the
water reservoir is filled as specified in the table (TF=tank
fillings).
Hardness range °dH
I soft 0-7
II Medium 7-14
III Hard 14-21
IV Very hard >21
Note
Your water board or municipal utilities authority can pro-
vide information on hardness of tap water.
ATTENTION
Damaged surfaces
The descaler may corrode sensitive surfaces.
Fill and empty the appliance carefully.
16
/MAX).
mmol/l TF
0-1.3 100
1.3-2.5 90
2.5-3.8 75
>3.8 50
1. Switch off the appliance, see Chapter Switching off
the device.
2. Allow the appliance to cool down.
3. Drain the water reservoir.
4. Remove the accessory/accessories from the acces-
sory holders.
5. Open the maintenance lock. To do this place the
open end of an extension tube on the maintenance
lock, insert this into the guide so it engages and
open it.
Illustration U
6. Drain the water completely out of the steam boiler.
ATTENTION
Appliance damage due to descaler
An unsuitable descaler or incorrect dosing of the descal-
er may damage the appliance.
Only use KÄRCHER descaler.
Use 1 dosing unit of the descaler for 0.5 l water.
7. Apply descaler solution to the descaler according to
the details.
8. Fill the descaler solution into the steam boiler. Do
not seal the steam boiler.
9. Allow the descaler solution to take effect for
approx. 8 hours.
10. Drain descaler solution completely out of the steam
boiler.
11. Repeat the descaling process if necessary.
12. Rinse the steam boiler 2-3 times with cold water in
order to drain all the descaler solution residue.
13. Drain the water completely out of the steam boiler.
14. Dry the mounting for the grid connection cable.
15. Close the maintenance lock with an extension tube.
Care of accessories
(Accessories - depending on scope of delivery)
Note
The micro fibre cloths are not suitable for dryer.
Note
When washing the cloths, observe the instructions on
the washing tag. Do not use any liquid softeners as this
will affect the ability of the cloths to pick up dirt.
1. Wash the floor cleaning cloths and covers at a max.
temperature of 60 °C in the washing machine.

Troubleshooting guide

Malfunctions often have simple causes that you can
remedy yourself using the following overview. When in
doubt, or in the case of malfunctions not mentioned
here, please contact your authorised Customer Service.
WARNING
Risk of electric shock and burns
Trying to eliminate faults while the appliance is connect-
ed to the mains or has not yet cooled down is always
dangerous.
Remove the mains plug.
Allow the appliance to cool down.
The water shortage indicator light flashes red and a
signal tone sounds
No water in the tank.
 Fill the water reservoir up to the "MAX" marking.
The water shortage indicator light is lit in red
No water in the steam boiler. The pump's overheat pro-
tection has triggered.
1. Switch the device off; see Chapter Switch off the de-
vice.
2. Fill the water reservoir.
3. Switch on the device; see Chapter Switching on the
device.
