Auxiliary Control Buttons

dtx300
There is only one auxiliary control available on the dtx300 which is designated as the Illuminators
relay. This auxiliary is a latching function i.e. press for ON, press for OFF, the LED will show when
the function is activated.
dtx400/400d.c.
There are four auxiliary function buttons on the dtx400 keyboard as shown below.
Their functions are as follows:
wash - Press and hold for the desired wash period
wipe - Press on/press off
autopan - Press, LED lights and the autopanning function begins. Press Pan Left or Pan
Right to stop
aux - Press on/press off

Self Test

dtx300
To run the self test procedure, press set and focus far. This command activates the self test routine
in all Dedicated Micros drx telemetry receivers. See the drx receiver handbooks for more
information
dtx 300, 400, 400d.c. Installation Manual
AND
= SELF TEST
Page. 6
