INSTALLING THE SWITCH HOUSING

Step 1. Remove the screw marked with a dot label which is preinstalled on
mounting plate and keep for later use. Loosen the other two (do not remove).
(Fig.19)
Step 2. Place the two slot holes on the switch housing over the 2 screws
previously loosened from the mounting plate. Rotate the switch housing until Mounting Plate
it locks in place at the narrow end of the key holes. Secure by tightening the 2
screws previously loosened and the one previously removed. (Fig. 20)
Screw
Fig. 19
Mounting Plate
Switch Housing
Screw
Fig. 20
54" Daya LED | 13
