QUERY
Draught circulates
around the door.
Condensation forms in
the oven, and may drip
from the door.
Flashing or arcing from
within the cavity when
cooking.
Arcing potatoes.
The display is lit but the
control panel will not
work when pressed.
Oven cooks too slowly.
Oven makes a noise.
Outer cabinet is hot.
Model name:
AC Line Voltage
Power Consumption: Microwave
Input Current:
Output power:
Heating Category
Microwave Frequency
Outside Dimensions (W ) x (H) x (D) mm
Cavity Dimensions (W ) x (H) x (D)** mm
Oven Capacity
Cooking Uniformity
Weight
* This product fulfils the requirement of the European standard EN55011.
In conformity with this standard, this product is classified as group 2 class B equipment.
Group 2 means that the equipment intentionally generates radio-frequency energy in
the form of electromagnetic radiation for the heat treatment of food.
Class B equipment means that the equipment is suitable to be used in domestic estab-
lishments.
** Internal capacity is calculated by measuring maximum width, depth and height. Actual
capacity for holding food is less.
AS PART OF A POLICY OF CONTINUOUS IMPROVEMENT, WE RESERVE THE RIGHT TO AL-
TER DESIGN AND SPECIFICATIONS WITHOUT NOTICE.
ANSWER
When the oven is working, air circulates within the cavity.
The door does not form an airtight seal so air may escape from the door.
The oven cavity will normally be colder than the food being cooked, and so
steam produced when cooking will condense on the colder surface.
The amount of steam produced depends on the water content of the food
being cooked. Some foods, such as potatoes have a high moisture content.
Condensation trapped in the door glass should clear after a few hours.
Arcing will occur when a metallic object comes into close proximity to the
oven cavity during cooking. This may possibly roughen the surface of the
cavity, but would not otherwise damage the oven.
Ensure all "eyes" are removed and the potatoes have been pierced, place
directly onto the turntable or in a heat resistant flan dish or similar.
Check the door is closed properly.
Ensure correct power level has been selected.
The microwave energy pulses ON and OFF during cooking/defrosting.
The cabinet may become warm to the touch - keep children away.
Microwave
Microwave
Grill
TROUBLESHOOTING

SPECIFICATIONS

: Single phase 230-240V, 50Hz
: 1200W
: 5.2A
: 800W (IEC 60705)
: 1000W
: E
: 2450MHz* (Group 2/Class B)
: 452 x 262 x 362
: 315 x 210 x 329
: 20 litres**
: Turntable diameter 245mm
: Approx. 12.5 kg
GB-34
R670
