pH ORP

Printing

You can print out the currently measured values and the calibration record.
Via the micro USB port, you can connect the Portavo 908 to a suitable printer.
To do so, use the included USB adapter (A female to B male).
The following printer protocols are supported: HP-PCL, Epson, Samsung, and IBM.
Required Settings in the "Configuration" Menu
(depending on the measured variable;
pH: page 14, Cond: page 18, Oxy: page 21)
• Select "Right softkey: Print".
• From the "Printer" submenu, select the driver for your printer and the paper size:
+ Printer
Driver
Paper

Printing Currently Measured Values

1) Use the included USB adapter (A female to B male) to connect a printer to the
micro USB port of the meter and switch it on.
2) Switch the meter on using the on/off or meas key.
Press the right softkey: Print.
The currently measured values will be printed.
Note:
A4 printers do not eject the paper immediately.
The printer collects several values until it prints the page. If you want to eject the
page before the print job is finished, you can press and hold the Print softkey
(for approx. 2 seconds).
3) You will receive a printout of the currently measured values with date and time
stamp (example):
Oxy Cond
Auto | HP PCL | Epson | Samsung | IBM
A4 | Small
Printing
