Dimensions

DT-V9L5
<Front view>
217
186
*at the higher position
**at the lower position
<Rear view>
100
75
Notice on transportation
This monitor is precision equipment and needs dedicated packing material for transportation.
Never use any packing material supplied from sources other than JVC or JVC-authorized dealers.
●
For easy understanding, pictures and illustrations are shown by being emphasized, omitted or composed, and may be slightly different
from actual products.
●
Design and specifications are subject to change without notice.
●
All company names and product names mentioned herein are used for identification purposes only, and may be the trademarks or
registered trademarks of their respective companies.
Unit: mm
<Side view>
26.5
1.3
13
VESA mounting holes
(8-M4, depth:10mm)
