Function Key Setting Specify the function assigned to the F1 button.
Function1 Specify the function assigned to the F1 button.
* See pages 13 to 22 for details of the functions assigned to Function 1.
Function Display Select whether to display the status of the assigned function when you press the F1 button.
Off
Mode-1
Mode-2
●
To display the "Function Key Setting" menu, press the
●
About the operations of F1 button
Each time you press the button, the setting value for the assigned function changes in order.
Ex: When "Color Temperature" is assigned
Each time you press the button, three setting values alternate.
Picture Sub Adjust
Configure the standard level of image adjustment.
Item To do
Contrast* 1 Adjust the standard level for the contrast adjusted with the CONTRAST knob on the front
panel.
Bright* Adjust the standard level for the brightness adjusted with the BRIGHT knob on the front
1
panel.
Chroma* Adjust the standard level for the chroma adjusted with the CHROMA knob on the front panel. –20 to +20
1
Phase* 1, * 2 Adjust the standard level for the phase adjusted with the PHASE knob on the front panel.
NTSC Setup Select the set-up level of the input NTSC signal.
Component Level Select the level of the analog component signal (480i and 576i only).
sub menu Display the sub menu which enables you to adjust the items in "Picture Sub Adjust" while viewing the actual picture.
reset Restore the default settings for all the items in "Picture Sub Adjust".
* 1 Memorized for each input.
(☞ page 18)
* 2 When "Component Phase"
White Balance Setting
Display the color temperature, and adjusts the drive level and cutoff point of each color (R/G/B).
Item To do
Color Temperature Select the color temperature. (Cannot be set/changed)
R Drive * 1 Adjust the drive level of each color (red, green, and blue).
●
G Drive The maximum (Max) and minimum (Min) values vary depending on the input signal or
B Drive other settings.
R Cut Off * Adjust the cutoff point of each color (red, green, and blue).
1
●
G Cut Off The maximum (Max) and minimum (Min) values vary depending on the input signal or
B Cut Off other settings.
sub menu Display the sub menu which enables you to adjust the items in "White Balance Setting" while viewing the actual picture.
reset Restore the default settings for all the items in "White Balance Setting".
* 1 Memorized for each color temperature.
: No status display. Perform the registration function.
: Display the status. Perform the registration function.
: Display the status. Do not perform the registration function.
Perform the registration function when the status is displayed and the button is
pressed again.
button when the menu is not displayed.
is set to "Disable," "Phase" cannot be adjusted if no NTSC signal is input.
- - -, Aperture, I/P Mode,
Frame, Center Marker,
Level Meter Display,
Gamma, Color
Temperature,
CRC Error, Manual Aspect,
Time Code, 1:1, Dynamic
Off, Mode-1, Mode-2
Setting value
–20 to +20
–20 to +20
–20 to +20
00 (compliant with 0 %
set-up signal), 7.5 (compliant
with 7.5 % set-up signal)
B75 (compliant with
BetacamVTR 7.5 % set-up
signal), B00 (compliant with
BetacamVTR 0 % set-up
signal), SMPTE (compliant
with M2VTR signals)
Setting value
9300K, 6500K, User
Min – 000 – Max
(in 1024 grades)
Min – 000 – Max
(in 1024 grades)
