4. NORMAL USE OF THE STOVE
The ash drawer and brazier must be cleaned before every start-up. See
section 6.4. In addition, the stove door must be closed.
The stove may not be used in conjunction with an air extractor system,
hot air heating or other appliances that have an effect on the air
pressure in the room. Such appliances must be switched off when the
pellet-burning stove is in use.

4.1 DISPLAY INFORMATION

Button 1: Lowers the room temperature desired by the user. Button 1 can also
be used to show and alter the level of heat output.
Button 2: Raises
Button 2 can also be used to show and alter the level of heat output.
Button 3: Is used to turn the stove on and off.
Receiver 4: Remote control receiver.
LED 5: Indicates an Alarm C (C stands for temperature) error. For more in-
formation, see section 8.2 "error list".
LED 6: Indicates an Alarm F (F stands for flue gases) error. For more infor-
mation, see section 8.2 "error list".
LED 7: The stove features a clock for setting the start-up and switch-off
times. When this LED is lit, the clock mode is active. Timer function
not activated for the models TBH 558 / TBH 564 / TBH 565 / TBH 570.
LED 8: Indicates that the set temperature has been reached. The text ECO
and the set temperature will also be shown on the display.
LED 9: Indicates that the pellet feed auger is active.
LED 10: Indicates that the hot rod igniter is active.
Display 11: Indicates the room temperature and the heat output In the event of
a fault, the error code is displayed.
LED 12: ON/OFF indicator.
the room temperature desired by the user.
