SyMBOLS
To reduce the risk of injury, user
must read instruction manual
Warning
Wear eye protection
Wear ear protection
Wear dust mask
Do not expose to rain or water
Do not burn
Do not dispose of batteries. Return
Li-Ion
exhausted batteries to your local
collection or recycling point.
Li-Ion
This product has been marked
with a symbol relating to removing
electric and electronic waste. This
means that this product shall not
be discarded with household waste
but that it shall be returned to a
collection system which conforms
to the European Directive 2002/96/
CE. It will then be recycled or
dismantled in order to reduce the
impact on the environment. Electric
and electronic equipment can be
hazardous for the environment
and for human health since they
contain hazardous substances.
Lithium-Ion cordless hammer drill
OpERATINg INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for driving in and
loosening screws as well as for drilling in
wood, metal and plastic.
BEFORE PUTTINg INTO OPERaTION
- BaTTERy CHaRgINg
A battery that is new or has not been used
for a longer period does not develop its
full capacity until after several charging /
discharging cycles.
A significantly reduced working period after
charging indicates that the batteries are used
and must be replaced.
- TO REMOvE OR INSTaLL BaTTERy
PaCK (See Fig.a)
Depress the Battery Pack Release Button (7) to
release and slide the Battery Pack (6) out from
your tool. After recharge, slide it back into your
tool. A simple push and slight pressure will be
sufficient.
1. ON / OFF SwITCH (See Fig.B)
Depress On/Off Switch (9) to start and release
it to stop your drill. The On/Off Switch is fitted
with a brake function which stops your chuck
immediately when you quickly release the
switch.
It is also a variable speed switch that delivers
higher speed and torque with increased
trigger pressure. Speed is controlled by the
amount of switch trigger depression.
waRNINg: Do not operate for
long periods at low speed because
excess heat will be produced internally.
2. SwITCH LOCK (See Fig.B)
The switch trigger can be locked in the OFF
position. This helps to reduce the possibility of
accidental starting when not in use. To lock the
switch trigger, place the Rotation Control (4) in
the center position.
3. REvERSIBLE (See Fig.B)
For drilling and screw driving use forward
rotation marked " " (lever is moved to the
EN
9
