CHARGER DISPLAY MODULE (CDM)

The IMPRES Adaptive Multi-Unit Charger can be enhanced with the
addition of a charger display module (CDM). For chargers with
software version 1.3 or later, order and install Motorola part no.
RLN5382. For chargers with software versions 1.2 or earlier and/or
non-marked labels, which require a flash upgrade, send the charger to
the Motorola Service Center to perform the upgrade and install the
CDM (part no. RLN5382).

General Display Information

The IMPRES Adaptive Multi-Unit Charger with CDM provides the user
with valuable information while performing battery maintenance and
care. The information that the charger displays and the corresponding
LED indicators are detailed in the following tables.
Start Up
Upon Charger Power-up
LED
Line 1
Line 2
If There is No Battery in the Pocket
LED
Line 1
Line 2
Reading Battery Data
LED
Line 1
Line 2
SINGLE FLASH GREEN
IMPRES
OFF
NO BATTERY
Any Defined Indication
READING
BATTERY DATA
16
