EQ SETTING
EQ PRESET FLAT / HARD ROCK / JAZZ / POP / R&B / TALK / USER1 / USER2 /
VOCAL BOOST / BASS BOOST / CLASSICAL / DANCE: Selects a preset
equalizer.
1 USER1/ USER2: Select a preset name.
EASY EQ
Default: 00 2 Adjust your own sound settings.
SUB.W * 1
: –08 to +08/ BASS LVL: –06 to +06/
MID LVL: –06 to +06/ TRE LVL: –06 to +06
1 USER1/ USER2: Select a preset name.
PRO EQ
2 BASS / MIDDLE / TREBLE: Select a sound tone.
3 Adjust the sound elements of the selected sound tone.
BASS Frequency: 60/ 80/ 100/ 200 Hz
Level:
Q:
MIDDLE Frequency: 0.5/ 1.0/ 1.5/ 2.5 kHz
Level:
Q:
TREBLE Frequency: 10.0/ 12.5/ 15.0/ 17.5 kHz Default: (10.0 kHz)
Level:
Q:
AUDIO
BASS BOOST * 2
+01 / +02: Selects your preferred bass boost level. ; OFF: Cancels.
LOUD 01 / 02: Boosts low or high frequencies to produce a well-balanced sound at
low volume. ; OFF: Cancels.
SUB.W LEVEL * 3
–08 — +08 (00): Adjusts the subwoofer output level.
SUB.W * 4
ON / OFF: Turns on or off the subwoofer output.
10
Default: XX
Default: (80 Hz)
–06 to +06
Q1.0/ Q1.25/ Q1.5/ Q2.0
Default: (1.0 kHz)
–06 to +06
Q0.75/ Q1.0/ Q1.25
–06 to +06
Q FIX
SUB.W LPF * 3
THROUGH: All signals are sent to the subwoofer. ; LOW 55Hz /
MID 85Hz / HIGH 120Hz: Audio signals with frequencies lower than
55 Hz/ 85 Hz/ 120 Hz are sent to the subwoofer.
FADER * 2 * 5
R06 — F06 (00): Adjusts the front and rear speaker output balance.
BALANCE * *
2 5
L06 — R06 (00): Adjusts the left and right speaker output balance.
VOL ADJUST –05 — +05 (00): Presets the volume adjustment level of each source
(compared to the FM volume level). Before adjustment, select the source
you want to adjust. ("VOL ADJ FIX" appears if FM is selected.)
AMP GAIN LOW POWER: Limits the maximum volume level to 30. (Select if the
maximum power of each speaker is less than 50 W to prevent damaging
the speakers.) ; HIGH POWER: The maximum volume level is 50.
D.T.EXP ON: Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
(00)
audio data compression. ; OFF: Cancels.
(Q1.0)
TEL MUTING *
6
ON: Mutes the sounds while using the cellular phone (not connected
(00)
through KS-BTA100). ; OFF: Cancels.
(Q1.25)
L/O MODE SUB.W / REAR: Selects whether rear speakers or a subwoofer are
connected to the REAR/SW line out terminals on the rear panel (through
(00)
an external amplifier).
(Q FIX)
*
1 Displayed only when [L/O MODE] is set to [SUB.W] and [SUB.W] is set to
[ON].
*
2 This adjustment will not affect the subwoofer output.
*
3 Displayed only when [SUB.W] is set to [ON].
*
4 Displayed only when [L/O MODE] is set to [SUB.W].
*
5 If you are using a two-speaker system, set the fader level to [00].
* 6
Does not work if [BT ADAPTER] is selected for [AUX] in [SRC SELECT].
AUDIO SETTINGS
