TV-out

You can also connect the multi scanner to a television via the TV-out port [13]. You can thus transfer
the displayed content to a TV screen. In this case, your television must have a suitable composite
video input. First, check the TV-out setting of the multi scanner as follows:
Press the Mode button [4] to access the main menu.
Select the option "TV" [22] using the buttons Right/Colour [14] or Left/EV [16] and confirm your
selection with the OK/Capture button [3]. The following options are available:
Choose between the TV standards PAL and NTSC. NTSC is the standard in the United States and
Japan, while PAL is used in Europe. This choice affects only the playback with the video cable.
After you have identified the TV standards, connect the multi scanner and TV as follows with the
video cable:
 Connect the jack plug of the supplied video cable to the TV-out port [13] of the multi scanner.
 Insert the yellow RCA connector of the supplied video cable into the composite video input of
your TV. Once the video cable is inserted in the multi scanner and in the TV, the screen [8] is
switched off automatically.
WARNING! When laying the cable, make sure that nobody can trip over it.
20 Select recording source
21 Format memory card
22 TV
23 USB mode
24 Energy-saving mode (automatic switch-off
after approx. 3 minutes)
41 PAL
42 NTSC
