Appendix
A.1 I/O Connections and Wiring
Note
Relays shown in Power OFF position, which is the same as the alarm assertion position.
*7ME39400AL00 Mercury Relay only available with Normally Open.
Terminal Block Wiring - 7ME39400AL03 and 7ME39400AL04 Expanded I/O Module
(Refer to manual drawing 1010N-7-7 sheet 2 of 2)
These connection diagrams apply to the part numbers listed below.
Table A- 4
FUS1010
FUE1010
FUH1010
56
Connection Diagrams and Part Numbers
1010N-7-7 (Sheet 2 of 2) Drawing
7ME3530, 7ME3533
7ME3500
Not Used
FUS1010 IP65 NEMA 4X & IP66 NEMA 7 Quick Start
Operating Instructions, 07/2014, A5E03086486-AD
