CUTOUT DIMENSION
NEIGHBOUR HOOD WALLS
WOOD /
CONCRETE OR CERAMIC
TILED
C1 (mm) C2 (mm)
560 490
MIN A (mm) MIN B (mm)
50 50
Apply one-sided self-adhesive sealing
tape supplied all the way round the
lower glass edge of the cooking sur-
face along the outer edge of the glass
ceramic panel. Do not stretch it.
· Screw the 4 worktop mounting brac-
kets on the side walls of the product.
Worktop mounting bracket
Making an electrical connecti-
on
Before making a connection, check
that:
The voltage power supply is the same
EN 15
