9.3. Changing Diaphragms and Valve Plates

Vacuum pump system is switched off and mains plug is

removed from the socket
Vacuum pump system is clean and free of hazardous materials

Qty Material
1 Phillips-head screwdriver No. 2
1 4-mm hexagon screwdriver
1 Service Set (see chapter 11, page 40)
1 Felt-tip pen
Tab. 5
 Always replace diaphragms and valve plates together to
maintain the pump performance.
Health hazard due to dangerous substances
in the vacuum pump system and pump!
Depending on the substance transferred, caustic
burns or poisoning are possible.
WARNING
 Wear protective clothing if necessary, e.g.
protective gloves.
 Flush vacuum pump system before replacing the
diaphragms and valve plates (see chapter 9.2.1,
page 30).
Danger of burns from hot pump parts
The pump head or motor may be hot even after the
pump has been shut off.
CAUTION
 Allow the pump to cool off after operation.
Remove pump head
1. Remove tubing from the inlet and outlet connectors of the
pump.
2. Undo the two screws (Fig. 14/1) and nine screws (2) of the
head cover (3).
3. Undo two screws (6) each, and remove both covers (5) at head
cover (4).
4. Lift the head cover (3) off the pump housing (17).
5. Lift off head plate (9) with intermediate plates (10), (13) and
(14).
