Spare parts

Only use the specified original Rais components!
If spare parts other than those recommended by RAIS are used, the warranty is
voided.
All replaceable parts can be bought as spare parts from your RAIS distributor.
For reference see spare parts drawing Q-Tee II (front of the user manual).
Pos. PCS.
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
30
Item number.
8392090
8391090
8392200
8383800
8384001
838121090
834121590USA
8391301
61-110
8340990USA
8385500
Description
Steel door
Glass door
Fire brick set
Shaking grate
Ash pan
Air guiding plate
Turbo plate
Smoke chicane
Flue collar for USA- England - 6"
Air damper
Seal set
