Care And Maintenance; Troubleshooting Guide; Specifications - Heath Zenith SECURE HOME DualBrite SH-4294-OR Instructions D'installation

• To prolong the original appearance, clean with clear water and a soft damp cloth only.
• Do not use paints, solvents, or other chemicals on this light fixture. They could cause a premature deterioration of the
finish. This is not a defect in the finish and will not be covered by the warranty.
• Do not spray with hose or power washer.
SYMPTOM POSSIBLE CAUSE
Lights will not 1.
come on. 2.
3. Fuse is blown or circuit breaker is turned off.
4. Daylight turn-off is in effect.
5.
6. Incorrect circuit wiring, if this is a new installation.
Lights come on in 1.
daylight. 2.
Lights come on for 1.
no apparent reason.
2.
Lights stay on 1.
continuously.
2. Light control is in Manual Mode.
3.
4.
Lights flash on 1.
and off. 2. Heat being reflected from other objects may be affecting the
Seasonal Temperature Changes – The closer the surrounding temperature is to a person's body heat, the less sensitive the sensor will appear. The greater
the temperature difference, the more sensitive the sensor will appear. The SENS control might need to be readjusted toward MIN or MAX as the outside
temperature changes for the different seasons. This is a normal part of the light sensor's operation.
Range ................................................................Up to 30 ft. (9.1 m) [varies with surrounding temperature]
Sensing Angle....................................................Up to 150°
Electrical Load ..................................................Up to 100 Watt Maximum Incandescent
Bulb Type ..........................................................Medium Base, Type "A", 100 Watt Maximum
Sensor Capacity .................................................Up to 360 Watt (3.0 A) Maximum Tungsten
Power Requirements ..........................................120 VAC, 60 Hz
Operating Modes ..............................................TEST, AUTO, and MANUAL MODE
ON-Timer .........................................................1, 5, 10 minutes
DualBrite® Timer ..........................................Off, 3, 6 hours, dusk-to dawn
Test Timer .........................................................5 Seconds
Manual Mode Timer .........................................Dusk-to-Dawn
206546-02

CARE AND MAINTENANCE

TROUBLESHOOTING GUIDE

Light switch is turned off.
Light bulb is loose or burned out.
Sensor not detecting movement.
Light control may be installed in a relatively dark location.
Light control is in TEST.
Light control may be sensing small animals or automobile
traffic.
Sensitivity is set too high.
The sensor may be picking up a heat source like an air vent,
dryer vent, or brightly painted, heat-reflective surface.
Light control is in DualBrite® mode.
Sensitivity is set too high.
Light control is in the TEST mode and warming up.
sensor.
SOLUTION
1.
2.
3.
4.
5.
6. Verify wiring is correct.
1.
2.
1.
2.
1.
2.
3.
4.
1. Flashing is normal under these conditions.
2.

SPECIFICATIONS

9
Turn light switch on.
Check bulb and replace if burned out.
Replace fuse or turn circuit breaker on.
Recheck after dark.
Re-aim the sensor to cover desired area. Adjust sensitivity
control.
The fixture is operating normally under these conditions.
Set control switch to 1, 5, or 10 minutes.
Re-aim sensor. Reduce sensitivity.
Reduce sensitivity.
Re-aim sensor. Reduce sensitivity.
Switch to Auto.
Slide DualBrite® switch to OFF position.
Reduce sensitivity.
Re-aim sensor. Reduce sensitivity.
