ASSEMBLY
STEP 11
8
Springs (x6)
STEP 12
8
Springs (x84)
Next, place 6 springs into the V-rings just left of the sockets, and stretch the
springs until they reach the frame holes just left of the sockets.
You now have attached 12 V-rings to the frame holes using 12 springs. There
should be 7 V-rings and 7 frame holes in between each spring.
Enclosure door
Now, place one spring directly to the left of each spring already placed.
Continuing in a clock-wise direction, attach the remaining springs to the
remaining V-rings and frame holes until all 96 springs have been placed.
19th
18th
17th
16th
15th
20th
21th
13th
26th
14th
12
(8)
Socket
22th
23th
24th
25th
