PerfectView M7LS
5

Technical description

5.1

Function description

The LCD monitor is a monitor which allows cameras (e. g. a rear view video camera) or
other video sources (e. g. a TV) to be connected. It is possible to switch back and forth
between video sources.
The monitor can be mounted on the dashboard, where it transmits the image from the
connected camera, allowing the driver to see the area behind the vehicle, e. g. when park-
ing.
The brightness of the monitor adapts automatically to the ambient light.
The buttons are illuminated and can therefore also be operated in the dark.
The mirrored picture function can be activated individually for each of the two video inputs.
The image then appears as if you were looking into the rear view mirror.
5.2

Operating elements

The following control elements are located on the monitor:
No. in
fig. d, Designation
page 8
1
2 C1/C2
3 –
4 MENU
5 +
6
EN
Description
Light sensor
Selects the camera or swaps menu page 1 and 2.
Reduces the volume or other selected parameters
(brightness, contrast, colour tint).
Switches to setup mode (see chapter "Using the
LCD-monitor" on page 35).
Increases the volume or other selected parameters
(brightness, contrast, colour tint).
Switches the monitor on and off.
Technical description
29
