Front view
(686 mm)
38
" Min.
/
3
4
(984 mm)
39" Max.
(990 mm)
Back view
NOTE: Most
installations require
a minimum of
5" (127 mm)
clearance behind
dryer for exhaust
vent with elbow.
See "Venting
Requirements."
3
/
"*
4
(18 mm)
*Approx. measurement.
Spacing for recessed area or closet installation
All dimensions show recommended and minimum spacing allowed.
Additional spacing should be considered for ease of installation and servicing.
■
Additional clearances might be required for wall, door, and floor moldings.
■
Additional spacing should be considered on all sides
■
of the dryer to reduce noise transfer.
For closet installation with a door, minimum ventilation openings in the top and bottom of
■
the door are required. Louvered doors with equivalent ventilation openings are acceptable.
Companion appliance spacing should also be considered.
■
ELECTRIC DRYER
PRODUCT MODEL NUMBERS
MED3500F, MED5500F, MED8200F
27"
(165 mm)
Power supply
cord/cable
Water inlet
(Steam models
only)
Vent
3
1
/
(89 mm)
(156 mm)
14
/
"
3
8
(365 mm)
Side view
Recommended installation clearances
6
/
"
1
2
29
"*
/
7
8
(759 mm)
"*
2
5"
(127 mm)
0"–5"*
(0 mm–127 mm)
6
/
"*
1
8
*0" (0 mm) spacing is allowed for straight-back venting only.
For steam models only, inlet hose must not be kinked.
3"
(76 mm)
18" min.
(457 mm)
3"
(76 mm)
1"
1"
(25 mm)
(25 mm)
W10775223A
48 in.
min.
2
(310 cm
)
2
24 in.
min.
2
(155 cm
)
2
12/2015
