Dot Clock
Dot Clock adjustments correct the interference
that appear as vertical banding in dot intensive
presentations like spreadsheets or paragraphs or
text in smaller fonts.
Select Dot Clock item by using " " or " " buttons.
Use " " or " " button to adjust the value.
PC Picture Menu
For adjusting PC picture items, do the following: Press
" " or " " button to select the second icon. PC Picture
menu appears on the screen.
Brightness, Contrast, Colour and Colour
Temperature settings in this menu are identical to
settings defi ned in TV picture menu under "Analogue
TV Menu System".
Note : If you set Colour Temp as User, you can defi ne R, G,
B settings manually.
Sound,Feature and Source settings are identical to thesettings
explained in Analog Tv menu system.

Displaying TV Information

Programme Number , Programme Name , Sound
Indicator and Zoom Mode information is displayed
on the screen when a new programme is entered or
INFO button is pressed.

Mute Function

Press " " button to disable sound. Mute indicator will
be displayed in the upper side of the screen.
To cancel mute, there are two alternatives; the fi rst
one is pressing the " " button and the second one
is increasing the volume level.
PIP (Picture-in-Picture) and
PAP (Picture-and-Picture)
Modes
Press the " /" " button once to switch to PIP
mode.
At PIP Mode, a small picture (PIP picture) is displayed
on the main picture. There are 1 size and 4 positions
(upper left, upper right, bottom left and bottom right)
available for the PIP window. Aspect Ratio of the PIP
window is fi xed and 4:3.
When PIP Mode is entered, the default active window
is the PIP window and the active window is indicated
by a yellow frame around it. The active window can
be changed by pressing " " or " " button. The status
info OSD belongs to active window. The place of the
status OSDs are same for both windows.
Press the " /" " button again to activate PAP
mode.
01_[GB]_MB36_MASQUE_HDIDTV-MPEG4_NICKEL7_32847W_3900UK_10067001_50162077.indd 28 01_[GB]_MB36_MASQUE_HDIDTV-MPEG4_NICKEL7_32847W_3900UK_10067001_50162077.indd 28
At PAP Mode, two pictures with equal sizes are
displayed on the screen. Aspect Ratios of the windows
are fi xed.
When you switch to PAP Mode, main window in PIP
Mode will be displayed on the right side of the screen.
The active window can be changed by pressing
" " or " " button.
Press the " /"
mode.

Picture Mode Selection

By pressing PRESET button, you can change Picture
Mode settings in accordance with your viewing
requirements. Available options are Dynamic, Natural,
Cinema and Pixellence.
Note : This function will not be available while in PC mode.

Freezing Picture

You can freeze the picture on the screen by pressing
the " OK " button on the remote control in TV mode.
Press the " OK " button to freeze picture. Press again
to quit freeze mode.

Zoom Modes

You can change the aspect ratio (image size) of the TV
for viewing the picture in different zoom modes.
Press "SCREEN" button to directly change the zoom
mode.
Available zoom modes are listed below.
Note:
In YPbPr and HDMI modes, while in 720p-1080i resolutions,
only 16:9 mode is available.
In PC mode, only 16:9 mode is available.

Auto

When a WSS (Wide Screen Signalling) signal, which
shows the aspect ratio of the picture, is included in
the broadcast signal or the signal from an external
device, the TV automatically changes the ZOOM
mode according to the WSS signal.
• When the AUTO mode does not function correctly
due to poor WSS signal quality or when you want to
change the ZOOM mode, change to another ZOOM
mode manually.
16:9
This uniformly stretches the left and right sides of a
normal picture (4:3 aspect ratio) to fi ll the wide TV
screen.
• For 16:9 aspect ratio pictures that have been
squeezed into a normal picture (4:3 aspect ratio),
English - 28 -
" button again to exit the PAP
