Interchange NSR83-21 Manuel D'utilisation page 20

Parts List for NSR83-21
ORDER
NO. DESCRIPTION
NO.
BOLT M6X45
1 610260
(Loctite 243)
2 320300 EXHAUST COVER
3 610220 BOLT M6X25
4 110040 CYLINDER CAP
5 520050 GASKET
6 520060 EXHAUST SEAL (A) 38 610090
7 110050 EXHAUSTOR
8 520070 EXHAUST SEAL (B) 40 320340
9 420260 EXHAUST VALVE
10 110060 PISTON BUMPER
11 510660 O-RING 48.5X3.5
12 310050 PISTON
DRIVER BLADE
13 322100
(Loctite 262)
14 510880 O-RING 90.5X2
15 510800 O-RING 63X2.4
16 110070 CYLINDER COLLAR 48 322140
17 510860 O-RING 79X2.45
18 310060 CYLINDER
19 510830 O-RING 69X2.45
20 520080 CYLINDER SEAL
21 620140 CYLINDER SPRING 53 420300
22 320310 SPRING SEAT
23 110080 CYLINDER RING
24 420270 BUMPER
25 410070 EXHAUST SLEEVE
26 110090 BODY
27 510820 O-RING 64X2.4
28 520090 BODY SEAL
BOLT M6X20
29 610200
(Loctite 243)
30 322250 GUARD COVER
31 210680 NOSE
BOLT M8X25
32 610300
(Loctite 243)
Parts Kits for NSR83-21
Kits de Partes Para NSR83-21
NOTICE: The parts listed in this
manual are for service assembly and
for reference. Changes to the tool
and drawing may be made without
notification.
Most parts or parts kits are available.
Contact your local dealer for more
information.
WARNING: When the tool needs
repairing or servicing, it is strongly
recommended that you contact your
local dealer. Do not disassemble the
tool yourself, which might waive your
right for product guarantee.
20
Lista De Partes Para NSR83-21
ORDER
NO. DESCRIPTION
NO.
33 640130 ROLL PIN 3X20
34 410080 HANDLE GRIP
BOLT M8X20 (Loctite
35 610280
243)
36 520100 END CAP SEAL
37 110100 END CAP
BOLT M5X18
39 640180 ROLL PIN 3X30
TRIGGER
41 640210 ROLL PIN 3X45
42 420290 SAFETY GUARD
43 620090 SAFETY SPRING
44 322120 SAFETY (B)
45 322130 ADJUSTER
46 620920 SPRING
47 630240 STEEL BALL
SAFETY (A)
49 324340 WASHER
BOLT M6X10 (Loctire
50 610160
243)
51 620160 PLUNGER SPRING
52 510100 O-RING 4X1.9
PLUNGER (A)
54 510330 O-RING 11.2X1.5
55 310070 VALVE BUSHING
56 510270 O-RING 9X1.9
57 310080 VALVE SLEEVE
58 510230 O-RING 7X1.5
59 510130 O-RING 4.6X1.5
60 320350 WASHER
61 620170 PLUNGER (B) SPRING
62 320360 PLUNGER (B)
63 410090 VALVE RUBBER WASHER
64 410100 RUBBER BALL
Liste Des Trousses De Pièces Pour NSR83-21
ORDER NO. DESC.
CODE
98648 NSR83K1
98650 NSR83K2
98652 NSR83K3
98654 NSR83K4
98656 NSR83K5
98658 NSR83K6
98659 NSR83K7
98660 NSR83K8
98661 NSR83K9
Interchange Brands Framing Nailers: Operator's Manual
Liste Des Pièces Pour NSR83-21
ORDER
NO.
NO.
65 320370
66 510340
67 310090
68 420310
69 510060
70 640440
71 620930
72 210710
73 322260
74 322270
75 610310
76 630300
77 620940
78 322290
79 322300
80 610780
81 610070
82 322310
83 610320
84 610330
85 322320
86 322330
87 610520
88 310400
89 630070
90 630310
P1 D322091 DRIVER UNIT
P2 T310071 PLUGER VALVE
P3 T310091 TRIGGER VALVE
KIT # ITEM
Kit #1 O-Ring/Gasket Kit for NSR83-21
Kit #2 Piston/Driver Assembly for NSR83-21
Kit #3 Head Cap Assembly for NSR83-21
Kit #4 Trigger Valve Assembly with Trigger for NSR83-21
Kit #5 Magazine Assembly for NSR83-21
Kit #6 Guide Body Assembly for NSR83-21
Kit #7 Safety Kit for NSR83-21
Kit #8 Feeder Kit for NSR83-21
Kit #9 Bumper Kit for NSR83-21
DESCRIPTION
VALVE PLATE
O-RING 11.2X2
TRIGGER VALVE
BUSHING
TRIGGER STEM
O-RING 3X1.8
STRAIGHT PIN B4X24
ROLL SPRING
NAIL FEEDER
FIXED PIN
YOKE
NUT M4 (Nylock)
WASHER
SPRING
SPRING SLEEVE
STOP LEVER
BOLT M4X30
BOLT M5X12
MAGAZINE BRACKET
NUT M5 (Nylock)
NUT M6 (Nylock)
HANDLE ARM
NAIL RAIL
BOLT M6X16
MAGAZINE
SPRING WASHER
WASHER
