Assembly and Operating Instructions
Selecting roller shutter
When the roller shutter function is used, the roller shutter remains locked after a
control button has been activated.
Selecting venetian blind
When the venetian blind function is being used, the venetian blind moves in
non¬maintained command mode in order to allow the slats to be positioned
more precisely. If you press and hold a control button for longer than 1 second,
the venetian blind will remain locked.
After the programmed intermediate position respectively lower final position has
been reached, the slats will be automatically adjusted (provided the reverse po-
sition has been programmed).
sliding switch
Use the sliding switch to toggle between automatic and manual for the selected
channel or the selected group.
The current setting is shown on the display.
Channel
The channel of a handheld transmitter can be programmed into one or several
receivers. One or several receivers are controlled via an individual or group com-
mand respectively.
Central command
If all the transmitter channels are selected, all the assigned receivers/receiver
groups can be controlled simultaneously.
Channel selector button
Note
Channel selection can only occur in operating mode.
The channel selector button may be used to select up to 10 channels. Operation
of the individual channels is indicated by the relevant LED lighting up.
Channel
1-5 and central command 1-5
6-10 and central command 6-10

1-10 central command

32

Explanations

LED colour
green
red
orange
