the fixture or one fixture with another.
Building a serial DMX-chain:
Connect the DMX-output of the DMX Scan Control with the DMX-input of the nearest projector. Always
connect one output with the input of the next fixture until all fixtures are connected.
Caution: At the last fixture, the DMX-cable has to be terminated with a terminator. Solder a 120
between Signal (–) and Signal (+) into a 3-pin XLR-plug and plug it in the DMX-output of the last fixture.
Projector addressing
Please note that the DMX Scan Control assigns the DMX-starting addresses every 16 steps. You have to
address every projector to the respective starting address. Otherwise, the channel assignment will not be
correct. All projectors with the same starting address work synchronically.
Projector Starting address
Projector 1 1
Projector 2 17
Projector 7 97
Projector 10 145

5.4 Adjusting the joystick

5.4.1 Assigning the joystick
Hold the Program-button, until the LED is lit.
Hold the Mode- and Fine-button at the same time until the Assign-LED is lit. If the Reverse-LED is lit hold the
Mode- and Fine-button once more.
Select the Pan- or Tilt-direction via the Bank Up and Bank Down-button.
Press the Tap/Display-button in order to adjust 16-channel or 8-channel mode.
Select the desired projector via the Projector Select-buttons.
Hold the Mode-button and press the Scene-button on whose channel the Pan- or Tilt-channel is located. E.g.
if the Pan-movement is on Fader 1, hold the Mode-button and press Scene-button 1.
Hold the Mode- and Fine-button at the same time in order to leave the Assign-mode.
5.4.2 Invert the joystick-movement or other DMX-channels
Hold the Program-button, until the LED is lit.
Hold the Mode- and Fine-button at the same time until the Reverse-LED is lit. If the Assign-LED is lit hold the
Mode- and Fine-button once more.
Select the Pan- or Tilt-direction via the Bank Up and Bank Down-button.
Press the Tap/Display-button in order to adjust 16-channel or 8-channel mode.
Select the desired projector via the Projector Select-buttons.
Hold the Mode-button and press the Scene-button on whose channel the Pan- or Tilt-channel is located. E.g.
if the Pan-movement is on Fader 1, hold the Mode-button and press Scene-button 1.
Hold the Mode- and Fine-button at the same time in order to leave the Reverse-mode.
Other DMX-channels could be reversed the same way.
5.4.3 Delete projector assign
With this function, you can delete the Pan/Tilt-assign of a projector.
Hold the Program-button, until the LED is lit.
Hold the Mode- and Fine-button at the same time until the Reverse or Assign-LED is lit.
Select the desired projector via the Projector Select-buttons.
Press the Mode and Auto/Del-button at the same time. All LEDs will flash three time. The desired projector
was deleted.
5.4.4 Delete all projector assigns
With this function, you can delete the Pan/Tilt-assign of all projectors.
Switch the device off.
Hold the Mode- and Auto/Del-button at the same time.
Turn the device on again. All LEDs will flash shortly, all DMX-channels are deleted.
5.4.5 Display DMX-channel
With this function, you can display the channel assigned to the Pan/Tilt-movement.
Hold the Mode- and Fine-button at the same time until the Reverse or Assign-LED is lit.
Projector Starting address
Projector 3 33
Projector 4 49
Projector 8 113
Projector 11 161
20/46
Projector Starting address
Projector 5 65
Projector 6 81
Projector 9 129
Projector 12 177
00042202.DOC, Version 2.2
resistor
