2.1 Main components

1 Grease filter cover-panel
3 Motor
5 Housing
7 Outer chimney
Also included: chimney fixing clamp, drill-hole stencil, instruction manual.

2.2 Installation steps

WARNING! Failure to install the screws or fixing device in accordance
with these instructions may result in electrical hazards.
WARNING! Do not damage the wiring in the wall while drilling
1. Drill three 8 mm holes to install the suspension bracket. Fix the suspension
bracket on the wall using the provided screws and dowels.
4
3
2
1
2 Grease filter
4 Cover panel (housing)
6 One-way valve
25
7
6
5
