WMBUS TEMP - Guide utilisateur / User guide version V2.0.0
321 1 Configuring the event behaviour of the
internal sensor
322 1 Configuration of the external sensor
323 1 Configuring the event behaviour of the
external sensor
324 4 High threshold value of the internal
sensor
325 1 Value of the high threshold hysteresis
of the internal sensor:
326 4 Low threshold value of the internal
sensor
327 1 Value of the low threshold hysteresis of
the internal sensor
328 4 High threshold value of the external
sensor
329 1 Value of the high threshold hysteresis
of the iexternal sensor:
330 4 Low threshold value of the external
sensor
331 1 Value of the low threshold hysteresis of
the exterbal sensor
332 1 Acquisition period
333 1 Super-sampling factor
A consistency check will be performed at the time of the registration of the settings via the AT&W command. If one of the following conditions
is verified, the command will return «W»:
• Period of transmission = 0 (register 301) and no active threshold (registers 321 and 323)
• Two active thresholds (registers 321 and 323), and the value of the high threshold is less than the value of the low threshold.
Hexadecimal Default 0x03
Bits 0 to 1: Threshold triggering
• 0 = None
• 1 = Low only
• 2 = High only
• 3 = Low and High
Bits 2 to 7: Reserved
Hexadecimal See details of register 320
Hexadecimal See details of register 321
Decimal Default: 300
Min/max: -550 to 1200 (signed value)
Units: tenth of °C
Decimal Default: 10
Min/max: 0 of 255 (Unsigned value)
Unit: tenth of °C
Decimal Défaut: 300
Min/max: -550 à 1200 (Unsigned value)
Unit: tenth of °C
Decimal Default: 10
Min/max: 0 à 255 (Unsigned value)
Unit: tenth of °C
Decimal Dfaut: 300
Min/max: -550 à 1200 (Unsigned value)
Unit: tenth of °C
Decimal Default: 10
Min/max: 0 to 255 (Unsigned value)
Unit: tenth of °C
Decimal Default: 300
Min/max: -550 à 1200 (Unsigned value)
Unit: tenth of °C
Decimal Default: 10
Min/max: 0 à 255 (Unsigned value)
Unit: tenth of °C
Decimal Default: 10
Min/max : 1 à 255
Unité:
x 1minute if S306=1
x 10 secondes if S306=2
Decimal Default: 5
Min/max: 1 à 10
Unit: aucune
FR
EN
59 of 77
