• Place the facecap assembly onto the TLR-3
Fully tighten the facecap assembly to ensure that the battery
makes complete contact with the internal electrical contacts.
Switch Operation
The TLR-3 /TLR-4
®
tion. The TLR-4
™
laser housing.
Constant
OFF (PADDLE)
Momentary
Laser
TLR-4 Laser Sight Zeroing
™
For a laser mounted below or to the side of the bore, there is only one distance where
the bullet path will coincide with the laser sight line. This point is the "zero range".
Laser adjustment and the muzzle velocity of the bullet determine where this point
occurs. The user must decide how high above or below the sight line the bullet can
be allowed to strike and adjust the sight accordingly. At distances less than the zero
range the bullet will be above the sight line. Beyond the zero range the bullet will be
below the sight line. If mounted to the side, the bullet will also deviate to the side of
the laser line, as well as up and down. In practice, a TLR-4
justed to keep the bullet strike within about 2" high and 2" low out to about 100 feet.
There are two adjustment screws (mounted in brass bushings) located on the laser
cartridge housing. The windage adjustment is located on the left hand side of the
laser cartridge. Turn the set screw clockwise to move the laser to the left (POI right).
Turn the set screw counter-clockwise to move the laser to the right (POI left). The
elevation adjustment is located on the underside of the TLR-4
the TLR-4 pointed down range a clockwise turn of the adjustment screw will move
™
the laser down (POI up). A counter-clockwise turn on the adjustment screw will move
features a paddle switch providing momentary or constant activa-
™
has an additional mode selection switch located on the rear of the
(TLR-4
/TLR-4
® ™
™
MODE SWITCH)
LED
body.
Momentary
OFF (PADDLE)
Constant
Laser/LED
on a handgun can be ad-
™
laser cartridge. With
™
