Rail Key Installation/Removal
THE TLR-3
/TLR-4
®
BEFORE THIS PROCEDURE CAN BE PERFORMED.
The TLR-3
/TLR-4
®
correct, select a key that will securely attach your TLR-3
with special regard for: width of key and rail slot, operation of the switch, and non-
interference with the trigger guard, etc. A list of factory-tested keys for weapons and
rails is included for reference.
NOTE: A key MUST be used or the TLR-3
of the rail under recoil.
Rail Key Installation
1. Unscrew the rail clamp tension
bolt and remove it completely (the
tension spring must stay with the rail
clamp tension bolt).
2. Place the key into the slot between
the movable portion of the rail clamp
and the fixed side. Note: The key
is fitted properly when the holes in
the rail clamp align with the holes
in the key.
3. Insert the rail clamp tension bolt through
the fixed side of the rail clamp,
through the key and tighten into the
movable side of the clamp.
4. Tighten the rail clamp tension bolt fully
against the fixed side of the rail clamp.
5. Place the e-clip onto the rail and align
the open end with the groove in the
threaded portion of the rail clamp
tension bolt.
6. Locate the "insert" side of the e-clip
tool and place it against the clamp surface.
7. Align the e-clip tool with the e-clip and push
the tool until the e-clip snaps into place.
Rail Key Removal
1. Fully tighten the rail clamp tension bolt.
2. The e-clip will become accessible on the end of
rail clamp tension bolt (not installed from the factory).
3. Locate the "removal" side of the e-clip tool and place
it against the clamp surface.
MUST BE REMOVED FROM THE FIREARM
™
is shipped with the "A" rail key installed. If the "A" key is not
™
/TLR-4
®
/TLR-4
will slide off the front
®
™
to the weapon
™
Rotate tool
and place
over e-clip.
