INSTRUCTIONS FOR USE
• Please read the instructions carefully before use.
• Use outdoors only.
• Do not use charcoal.
• Do not use an adjustable low pressure regulator. Only use fixed regulators that comply with relevant European
Standards.
• Do not put a metal plate that has not been designed or recommended by CAMPINGAZ on or in place of the cooking grill.
• Regularly clean the parts at the frame bottom to avoid risk of inflammation from fat drippings.
Follow these instructions carefully to avoid serious damage to your barbecue.
A. FOR yOUR SAFETy
y Do not store or use petrol and other flammable liquids or
vapours in the vicinity of this appliance. This device must
be kept away from inflammable materials when it is in use.
If you smell gas:
1. Close the valve of the cylinder.
2. Extinguish all naked flames.
3. Open the lid.
4. If the smell continues, see "F. Checking for gas leaks" or
immediately seek advice from your local retailer.
y Do not leave your appliance unattended while it is working.
y Parts which are protected by the manufacturer or the
manufacturer's representative must not be manipulated by
the user.
y Close the gas cylinder after use.
B. LOCATION
y This appliance must only be used outdoors.
y CAUTION: Accessible parts may get very hot. Keep young
children away.
y There should be no combustible materials within a radius of
approximately 60 cm around the appliance.
y Do not move the appliance when alight.
y The appliance should be operated on a level surface.
y Estimated air offtake is 2 m
C. GAS CyLINDER
This appliance has been adjusted to operate from 4.5 to 15
kg butane/propane cylinders with an appropriate low pressure
regulator:
y France, Belgium, Luxembourg, United Kingdom, Ireland,
Portugal, Spain, Italy, Greece :
butane 28 mbar / propane 37 mbar.
y Netherlands, Czech Republic, Slovakia, Hungary,
Slovenia, Norway,
Switzerland, Bulgaria, Turkey, Romania, Croatia:
butane 30 mbar / propane 30 mbar.
y Poland: propane 37 mbar.
y Germany, Austria: butane 50 mbar / propane 50 mbar.
Always connect or replace the cylinder in a well-ventilated
area, never in the presence of a flame, spark or heat source.
The possibility of putting the gas cylinder under the appliance
depends on the model used and the height of the cylinder. See
assembly manual.
When the gas cylinder is put under the appliance, it must be
attached to the frame of the appliance using the supplied strap.
See assembly manual.
D. HOSE (FIG. 1)
The appliance should be used with flexible hose that is suitable
/kW/h.
3
Sweden, Denmark, Finland,
for use with butane and propane gas. Hose length should not
exceed 1.50 meters. It should be replaced if it is damaged or
cracked, when required by national regulations or at the end of
its lifecycle. Do not pull or pierce the hose. Keep away from any
parts of the appliance that get hot. Check that the flexible hose
stretches out normally, without twisting or pulling.
France (depending on model) -
The appliance has a G 1/2 threaded gas inlet connector supplied
with pre-fitted NF ringed tailpiece and seal.
The appliance may be used with two types of flexible hose:
a. Flexible hose designed to be joined onto ringed tailpieces on
both the appliance and regulator sides, held firm with collars
(in accordance with standard XP D 36-110). Recommended
length 1.25 m.
To use the appliance with the flexible hose XP D 36-110
(Fig. 2):
1. Slide the flexible hose onto the ringed tailpiece on both
the appliance and regulator as far as it will go.
2. Slide the collars behind the two first bosses on the
tailpieces and tighten them until the tightening head
breaks.
3. Check for leaks following the instructions in Section F.
b. Flexible hose (according to standard XP D 36-112) fitted
with a G 1/2 threaded nut for fixing to the appliance and a M
20x1.5 threaded nut for fixing to the regulator, recommended
length 1.25 m.
To use the appliance with the flexible hose XP D 36-112, G
1/2 and M 20x1.5 nuts (Fig. 3):
1. Loosen and remove the NF ringed tailpiece to release the
G 1/2 inlet connector.
2. Remove the seal.
3. Tighten the G 1/2 threaded nut of the hose onto the
appliance inlet connector and the M20x1.5 threaded
nut onto the regulator output connector following the
instructions supplied with the flexible hose.
4. Use a spanner to hold the appliance inlet connector
firm and tighten or loosen the threaded nut with another
spanner.
5. Use a spanner to hold the regulator outlet connector firm.
6. Check for leaks following the instructions in Section F.
Belgium, Luxembourg, United Kingdom, Ireland, Portugal,
Spain, Italy, Croatia, Greece, Netherlands, Czech Republic,
Slovakia, Hungary, Slovenia, Norway, Sweden, Denmark,
Finland, Bulgaria, Turkey, Romania, Poland:
The appliance is equipped with an international connector.
Switzerland, Germany, Austria:
Flexible hose connection (Fig. 4): to connect the hose to the
connector on the barbecue, tighten the nut on the hose firmly
but without excess force using the two wrenches:
y no. 14 wrench to tighten the connector
y no. 17 wrench to tighten the nut on the hose
E. LID
