GB
SPARE PARTS AND ACCESSORIES
11.2
SPARE PARTS SF 23 PRO
ITEM ORDER NO. DESIGNATION
1 9953696 Motor protection switch
2 2393002 Oval-head tapping screw 4,2 x 45 (2 pcs.)
3 2393003 Oval-head tapping screw 4,2 x 25 (2 pcs.)
4 2388381 Oval-head tapping screw 4,2 x 22
5 2388377 Disc
6 2369533 Cover
7 2304608 Round cord
8 2393015 Capacitor 25uf 400V assy.
9 2393018 Oval-head screw M4x18 (4 pcs.)
10 2393035 Terminal box assy. (pos. 7-9)
11 2369517 Motor seal
12 2369436 Reducing double nipple
13 0340257 Pressure gauge assy. AUS
14 2369454 Inlet
15 2388291 Inlet valve housing
16 2369455 Clamp
17 2393043 Inlet valve assy. (incl. pos. 18)
18 2369458 Sealing ring
19 2393044 Oil level measuring set
20 2369586 Fitting
21 2393047 Pressure relief knob assy.
22 2369631 Pressure relief valve (incl. pos. 23)
23 9971395 O-ring
24 2398248 Label SF 23 Pro
25 0252475 Pressure gauge assy. EU
26 2393102 Outlet valve housing assy.
27 2393105 O-ring and sealing ring
28 2393106 Outlet valve assy. (incl. pos. 27)
29 2388374 Cable gland
30 2394776 Mains cable EU
0341520 Mains cable AUS
31 2400157 Mains cable assy. EU (pos 29-30)
2400156 Mains cable assy. AUS (pos 29-30)
60
Super Finish 23 Pro
