3.
INSTALLATION
THE BURNER MUST BE INSTALLED IN CONFORMITY WITH LEGISLATION AND LOCAL STANDARDS.
3.1 BOILER FIXING
Insert the recirculating pipe (6) in the flange seat (1) and lock with the screw (7), (see fig. 2).
Put on the flange (1) the screw (9) and two nuts (10), (see fig. 3).
Widen, if necessary, the insulating gasket holes (5), (see fig. 4).
Fix the flange (1) to the boiler door (4) using screws (2) and (if necessary) the nuts (3) interposing the
insulating gasket (5), (see fig. 5).
Fig. 2
7
E9055
2
Fig. 5
WARNING
Verify that the installed burner is lightly leaned towards
the button.
In order to allow this operation, the insulating gasket (5)
must be installed with the higher thickness faced down
(see fig. 6).
2899
6
1
5
1
2
E9056
Fig. 3
10
3
4
Fig. 6
3
GB
9
E9051
1
Fig. 4
5
D5012
max. 95 mm (417T)
max. 105 mm (418T)
5
D1959
