Peg-Perego VIAGGIO 2-3 Mode D'emploi page 25

6• The headrest can be adjusted in 6
el.
positions. Lift the handle on the rear
hild
of the backrest and position it at the
the
desired height.
IMPORTANT: as the child grows,
the
it is necessary to adjust the height
t as
according to the stature of the
rd.
child.
ing
IMPORTANT: after completing
2/3,
the operation, try moving the
out
headrest to verify that it is correctly
fitted in place.
7• Viaggio2/3 is fitted with two lateral
uct
and removable drink holders.
age
8• Viaggio2/3 is fitted with a reclination
me
system that guarantees maximum
comfort. To recline the seat, pull the
rest
handle on the front and simultaneously
lift the seat.
ory
9• If possible, recline the car's backrest
the
while the child is asleep and then
ons
recline the backrest of the child seat to
the same slant.
The Viaggio 2/3 backrest will adapt to the
slant of the car's backrest, guaranteeing
greater comfort for your child.
pen
Fitting the child car seat
the
as
with the safety belts and
Surefix fittings
the
For cars fitted with Isofix
eat
hooks
This method can be used only if the car
the
is fitted with Isofix hooks.
For further information on the
the
availability of these hooks and their
location, refer to the instruction manual
of the car. Surefix fittings guarantee
a greater safety, but cannot replace
the function of safety belts.
10• To stretch the Surefix hooks, press
the button on the front inside the bag,
as shown in the figure, and stretch
them manually.
11• Fix the Surefix connectors to the
Isofix hooks of the car seat, verifying
that they "click" in place (Arrow A).
Tension the belt and simultaneously
push the child car seat (Arrow B)
towards the backrest of the car seat
(Arrow C).
IMPORTANT: after completing
the operation, try moving the seat to
verify that the Isofix fittings have been
correctly hooked to the Isofix fittings .
12• To detach the Surefix connectors of
the child car seat from the Isofix hooks,
press the button on the front inside
the bag and release the connectors
belts in order to be able to manually
detach them by pressing the safety
lever situated on the hooks, as shown
in the figure.
Fitting the child car seat
with the safety belts
For cars that are NOT
fitted with Isofix fittings
13• Place Viaggio 2/3 on the car seat in
the direction of travel, as shown in the
figure, and place the child on the seat.
How to secure your child
on Viaggio 2/3
14• Secure your child with the car
safety belt as shown in the figure.
15• Fix the car safety belt to the car,
25
