OPERATING INSTRUCTIONS
tighten by turning to the right. Always adjust
both set screws by the same amount.
3. Close handle clamp.
4. Check the tension.
Stabilizer bar
When the saw is not fitted to a bench, always fit
the stabilizer bar (39) into the holes at the rear
of the saw base.The stabilizer helps prevent
the saw from tipping backwards when the slide
action is used.
Release knob
The release knob (6) is provided for holding the
cutting head down while transporting or
storing the mitre saw.The saw must never be
used with the release knob locking the head
down.
Slide lock
When tightened, the slide lock (29) prevents
the saw head from sliding.Tighten the slide
lock during transportation.
Mitre table lock (B10)
The mitre table lock (25 ) is used to lock the
table at the desiredmitre angle.
The mitre saw cuts from 0° to 45° both left and
right.To adjust the mitre angle loosen the mitre
table lock (25), push the locking button (25A)
and using the mitre table handle adjust the
mitre angle to the desired position.The mitre
table features positive click stops at 0°,
15°, 22.5°, 31.6° and 45° for quick setting of
common mitre angles.
WARNING. Be sure to tighten the mitre table
lock (25) before making a cut.Failure to do so
could result in the table moving during the cut
and cause serious personal injury.
Bevel lock (B1)
The bevel lock (16) is used to set the blade at
the desired bevel angle.The mitre saw bevel
cuts from 0° to 45° to the left and right.To
adjust the bevel angle loosen the bevel lock
and pull out the 0° bevel adjuster (18). Adjust
the saw arm to the desired bevel angle.
WARNING.Be sure to tighten the bevel lock (16)
before making a cut. Failure to do so could
result in the saw arm moving during the cut
and cause serious personal injury.
Bevel adjuster (B1)
The bevel adjuster (18) needs to be pulled out
before the bevel angle can be adjusted.
To return the saw arm to the vertical (0° bevel)
position move the saw arm to the left and push
in the 0° bevel adjuster (18).
Return the saw arm to the vertical position, it
will automatically stop at the 0° bevel position.
Please recheck and confirm it, if not exactly to
0º, please adjust it and then tighten the bevel
lock (16)
Adjustments
WARNING: Disconnect plug from power
source before performing any assembly,
adjustment or repair to avoid possible injury.
NOTE: Your miter saw was completely adjusted
at the factory. However, during shipment, slight
misalignment may have occurred. Check the
following settings and adjust if necessary prior
to using this miter saw.
Checking 0° Bevel Adjustment
1. Lower head assembly and engage head
assembly release knob (6).
2. Slide head assembly completely to the back
and tighten the slide lock (29).
3. Rotate miter table (21) to 0° miter position
4. Untighten the bevel lock (16)
5. Pull out the bevel adjuster (18)
6. Adjust the saw arm to the 0° bevel angle
7. Pull in the bevel adjuster (18)
8. Use a combination square to check saw blade
(42) squareness to the table. Place the square
on the table and press it against the saw blade
(42). The saw blade must contact the full length
of the square.
9. Tighten the bevel lock (16)
