immediately discontinue use and see your doctor about
these symptoms.
WARNING
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
KNOW YOUR PRODUCT
See page 81.
1. Gear selector (drill or hammer mode only)
Mode selector
3. Keyless chuck
Direction of rotation selector
5. Variable speed switch trigger
6. Handle, insulated gripping surface
7. LED light
8. Bit storage
9. Screw driver bit
10. Battery port
ELECTRONIC PROTECTION
This drill includes advanced electronics designed to protect
any of these protections are triggered.
a case of overload, this resets as soon as the trigger is
released. It is recommended that you change to speed 1
application.
case of low voltage. It is recommended that you recharge
your battery to complete your application.
a case of excessive internal temperature. The drill cannot
resume working until it cools down to a normal temperature.
MAINTENANCE
WARNING
The product should never be connected to a power supply
cleaning, performing maintenance, or when the product
is not in use. Disconnecting the product will prevent
When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloths to remove dirt and carbon dust.
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.
Always wear safety goggles or safety glasses with side
shields during power tool operation or when blowing
dust. If operation is dusty, also wear a dust mask.
For greater safety and reliability, all repairs should be
performed by an authorised service centre.
2
| English
LUBRICATION
All of the bearings in the product are lubricated with a
the product under normal operating conditions. Therefore,
no further lubrication is required.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
of as waste. The machine, accessories and
packaging should be sorted for environmental-
friendly recycling.
E-TORQUE CONTROL
e-Torque control is a technology which automatically drives
When in the auto screw driving mode the drill will stop once
depressing the trigger. The drill will begin small rotations at
a manageable speed. Release the trigger once the desired
depth is achieved.
When using e-Torque control it is important to ensure the
screw bit is correctly seated and does not slip from the
stop early to prevent damage to the screw head or bit. If
this occurs, realign the bit with the screw head and depress
the trigger again.
NOTE: e-Torque control works with most materials and
applications but may not operate with certain materials or
screws, e.g., machine screws into metal or plastic threads.
SYMBOLS
Safety alert
CE conformity
V
Volts
Direct current
min
Revolutions or reciprocations per minute
-1
Chuck capacity
No-load speed
EurAsian Conformity Mark
Please read the instructions carefully
before operating the product.
Ukrainian mark of conformity
Drilling without impact
