Denon UD-M31 Mode D'emploi page 9

7 REMOTE CONTROL UNIT
The UD-M31 comes with a system remote control unit (RC-933).
• The supplied remote control unit (RC-933) is for use with the UD-M31 unit only.
• If the cassette deck (DRR-M31) of the D-M31 series are connected to the main unit, you may operate each of the
above components using its respective remote control unit (refer to page 9,10).
(1) Inserting the batteries
q Open the battery compartment cover of the remote
control unit.
Press the knob and open the cover in the direction of
the arrow.
w Insert the two R03 (AAA) batteries, following the + and
– marks in the battery compartment.
e Close the cover of the battery compartment.
(2) Using the Remote Control Unit
B
7m
30°
30°
• The remote sensor is located on the CD receiver. Point
the remote control unit at the remote sensor as shown
on the diagram when operating it.
• The remote control unit will operate from a direct
distance of approximately 7 meters, but this distance
will be shortened if obstacles are present or if operated
at an angle. (The remote control unit will operate at an
angle of up to 30° in either direction.)
Cautions on Batteries
• Use R03 (AAA) batteries in this remote control unit.
• Replace the batteries with new ones after
approximately 1 year, though this depends on the
frequency with which the remote control unit is
used.
• Replace the batteries with new ones if the unit does
not operate when the remote control unit is
operated from nearby, even if the batteries are less
than a year old.
• Be sure to insert the batteries in the proper
direction, following the " < " and " > " marks in
the battery compartment.
• To avoid damage or leakage of battery fluid:
• Do not use a new battery with an old one.
• Do not use two different types of batteries.
• Do not short-circuit, take apart, heat or dispose of
batteries in flames.
• Remove the batteries when you do not plan to use
the remote control unit for an extended period of
time.
• If the battery fluid should leak, carefully wipe off the
fluid from the inside of the battery compartment,
then insert new batteries.
NOTES:
• The remote control unit may not operate if the
remote sensor is exposed to direct sunlight or the
strong light from a lighting fixture, or if there is an
obstacle between the remote control unit and the
remote sensor.
• Do not press buttons on the remote control unit and
on the set at the same time. Doing so could result
in malfunctions.
• If the remote control unit is pointed away from the
re-mote sensor during continuous operations (such
as when turning the volume up or down), the
operation will stop. If this happens, point the remote
control unit at the remote sensor and press the
button again.
(3) Remote Control Unit Part Names and Functions
CD function buttons
TIME button
EDIT button
• Press this button during the play or
• Press this button to input the
pause mode to switch the time
station name.
display.
TUNING • and ª buttons
elapsed time per track
• Use these buttons to selecting
↓
the station.
remaining time for the track
MEMORY button
↓
• Press this button to preset
total remaining time on the disc
memory.
(During programmed playback,
indicate the total remaining time of
the programmed tracks.)
EDIT button
• Press this button for edited
recording on a tape, dividing the
TITLE/CHARACTER
tracks onto sides A and B
according to the length of the tape.
and
6 7
(manual search) buttons
RANDOM
and
8 9
(automatic search) buttons TUNING
2 (stop) button
RDS
REPEAT
TUNER button
• Press this button to set the
PTY
function TUNER mode.
PROG /
DIRECT
CD 1 / 3 (play/pause) button
CD-R
GROUP
• Press this button to play or pause
CT
of the CD player.
DISC
SKIP
CD function buttons
RANDOM button 1
• Press this button to set the tracks CALL
in random order.
4
REPEAT button
PANEL
• Press this button for repeat
7
playback.
PROG/DIRECT button
10
• Press this button to switch
between PROGRAM and DIRECT
play.
CALL button
• Use this button to confirm the
programmed song.
TUNER function buttons
PRESET • / ª button
• Use these buttons to recall
preset stations on the tuner.
BAND button
• Use this button to selecting the
band.
FM AUTO FM MONO
AM
Power operation button
• Use this switch to turn on the
power of the entire system or set
SYSTEM
the power to STANDBY mode.
POWER
TIME
SLEEP button
EDIT
• Press this button to set the sleep
SLEEP
timer.
TUNING
ENTER
FUNCTION button
MEMORY
FUNCTION
TONE /SDB
• Press this button to switch the
TUNER
input (function).
• The input changes in the following
PRESET
- +
order each time this button is
pressed.
BAND
CD TUNER
MD
TAPE AUX
VOLUME
CD
TONE/SDB button
• Press this button to adjust SDB
2 3
(Super Dynamic Bass) and TONE.
DISPLAY
5 6
VOLUME button
• Use these buttons to adjust the
8 9
volume.
CLEAR
• The volume increases when the •
+10
button is pressed and decreases
when the ª button is pressed.
TAPE
DISPLAY button
• The display changes in the
B
following order each time this
RC-933
button is pressed.
Volume level Volume level Clock Clock
Function
Function
CD function buttons
Number buttons
• Press these buttons to specify the
desired track.
CLEAR button
• Press this button to clear the track
from the program.
TUNER function buttons
Number buttons
• Press these buttons to recall
preset station
CLEAR button
• Press this button to erase the
station name.
ENGLISH
9
