8.6

Specific application: succession of columns in a line.

In case some columns are installed in a line, change the type of synchronization cable alternatively
from a barrier to an other.
Synchro
E
Type 1
Change the type synchro
of the Rx
1. Click on "Column" Tab.
2. Keep "Alt" button pushed and press on "F8".
Alt
3. A window will pop-up in order to authorized the scripts.
Make a "right click" in the Frame, then select "Temporarily authorized the scripts windows".
A window will pop-up in order to authorized the scripts
4. Keep "Alt" button pushed and press on "F8".
Alt
5. A dialog box pops-up.
In this dialog box, enter the password in "admin" mode, by default 4 spaces.
Confirm by clicking on "OK"
Synchro
R E
Type 2
+
F8
+
F8
Synchro
R E R E
Type 3
Change the type synchro
of the Rx
- 76 -
MAXIRIS 3000 / 3100
Synchro Synchro
R E
Type 4 Type 1
Change the type synchro
of the Rx
"right click" in the Frame,
then select "Temporarily
authorized the scripts
windows"
Confirm by
clicking on "OK"
Enter the password
in "admin" mode
R
