230V AC / 110V AC power supply description:
12V DC power on,
green LED
Heater on, red LED
Cut off 12V DC jumper
Description of the12V DC interface:
Used on yellow side for double face column.
Heater fuse,
2A fast
Remark: if the 230V AC / 110V AC power supply is powered off (on the power supply block), the
both directions would be powered off (whatever the 12V DC interface state).
3

IMPLEMENTATION PRECAUTIONS

To install columns correctly, it is important to observe certain rules:
Have a stable
Do not position the cells facing
support
Power supply fuse,
1A fast
direct sunlight
Be sure that beams cannot be obscured by vegetation
in any season
- 46 -
MAXIRIS 3000 / 3100
Automotive fuse,
5A 32V for battery
12V DC power on,
green LED
Heater on, red LED
5° minimum
