ENCASTRÉ MT VERNON E2
MISE EN GARDE
Risque de choc
- Ne retirez pas la broche de mise à la terre de la
prise.
- Branchez directement dans une prise correctement
enfilée et à une broche.
- Arrêtez le câble loin de l'appareil.
- Ne placez pas le câble sous ou devant l'appareil.
22
Figure 22.1
I. Power Cord
1. Prior to installing the power cord, turn the dial control
"OFF".
2. Make sure the wall receptacle has 120vac output.
NOTE: Using a circuit protector can protect the appli-
ance circuits from power surges.
3. Remove the right side panel by releasing the upper,
spring-loaded latch. Access the latch through the upper
panel vent holes. The cast panel should fall forward.
Lift it out of its lower nest and set the panel aside. You
may need to disconnect the dial control wire harness.
4. Connect the power cord to the appliance first.
5. Route cord behind panel set.
FC7082-131K
12 mai, 2017
